The M90 closes the gap between M40 and ARRIMAX 18/12, which sits almost exactly in the middle between the two. The unit is focusable from 15° up to 49° just by turning the focus knob, producing a remarkably even light field and a crisp, clear shadow. The elimination of spread lenses speeds up the workflow on set.


In Stock
Ask about product
ARRI M90 M-Series

ARRI M90 M-Series




Category
HMI
Series
M-Series
Model
M-Series M90
Mains Plug
VEAM
Reflector
MAX Technology reflector made of high purity aluminium
Power Consumption
9000 W / 6000 W
Voltage Range
160 V / 123 V
Lamp Base
GX38
Dimming
yes, 50 to 100 % via ARRI Ballast Unit
Correlated Color Temperature
6000 K
Beam Angle
16° to 49° (with 9,000 W lamp)
Weight in kg net*
40 kg
Measurements (HxWxL) in mm*
947 x 713 x 720 mm
Lens / UV-Protection Glass Diameter in mm
500 mm
Accessory Diameter in mm
571 mm
Housing Color
Blue/Silver, Black
Protection Class / IP Rating
1 / IP 23
Certifications
CE, UKCA, CB, ENEC, cNRTLus
97398
Used
