Sony ECM-680S M/S Stereo Shotgun Microphone
The Sony ECM-680 Stereo Shotgun Microphone provides both M/S (Mid-Side) stereo, and mono audio capturing, at the touch of a switch. The electret-condenser, unidirectional (cardioid) ECM-680, features internal M/S decoding for true stereo placement.
Microphone
Polar Pattern Supercardioid / Unidirectional
Element Type 2x Electret Condenser
Sound Field Mono / Stereo
Orientation End Address
Controls Polar Pattern, Low Cut/HPF, Mono/Stereo
Pad No
Circuitry Solid-State
Performance
Frequency Response
50 Hz to 20 kHz (Cardioid)
40 Hz to 20 kHz (Supercardioid)
Maximum SPL 124 dB
Sensitivity
-28 dB (Cardioid)
-32 dB (Supercardioid)
Dynamic Range
104 dB (Cardioid)
106 dB (Supercardioid)
Equivalent Noise Level
21 dB (Cardioid)
20 dB (Supercardioid)
Connectivity
Analog Output 1x XLR 5-Pin Male
Power
Power Sources Phantom Power
Operating Voltage 40 to 52 V
Physical
Color Black
Mounting Thread Size 5/8"-27 Female (3/8"-16 Female with Included Adapter)
Dimensions ø: 0.8 x L: 9.8" / ø: 20 x L: 250 mm
Weight 3.7 oz / 105 g
